Gree GMV-80WL/C-T

GREE DC Inverter Multi VRF System II Service Manual
155
Parts list
NO.
Name of Part
GMV-120WL/A-T,GMV-140WL/A-T,GMV-160WL/A-T
Product Code
CN850W0180 /CN850W0170/CN850W0160
Part Code
Quantity
1
Coping
01264100008P
1
2
Inductance Assy
01394100050
1
3
Inductance
43120122
1
4
Electric Box Assy
01394100124
1
5
Main Board
30228000005
1
6
Radiator
49018000013
1
7
Filter Board
30228000006
1
8
Main Board
30226000045
1
9
Terminal Board
42018000026
1
10
Terminal Board
42011242
1
11
Left Side Plate
01314100013P
1
12
Clapboard Sub-Assy
01244100006
1
13
Fan Motor
15704115
1
14
Sensor Sub-Assy
39008000061G
1
15
Fan Motor
1570411501
1
16
Front Grill
26904100026
1
17
Cabinet
01514100002P
1
18
Front Side Plate
01314100012P
1
19
Handle
26235253
1
20
Front Connection Board
01344100002P
1
21
Diversion Circle
10474100001
1
22
Axial Flow Fan
10434100003
1
23
Chassis Sub-Assy
0119410000301P
1
24
Motor Support Assy
01804100293
1
25
Pressure Protect Switch
4602000902
1
26
Discharge Tube Sub-Assy
04534100057
1
27
Silencer
07444105
1
28
Oil Separator
07424105
1
29
Compressor
00204100001
1
30
Electrical Heater(Compressor)
765152128
1
31
Compressor Gasket
76710247
1
32
Cut off Valve
07330000002
1
33
Strainer
07212001
1
34
Gas-liquid Separator
07424100014
1
35
Capillary Sub-Assy
04004100013
1
36
Strainer
07415200002
1
