Gree GMV-80WL/C-T

GREE DC Inverter Multi VRF System II Service Manual
158
NO.
Name of Part
GMV-120WL/A-X
ǃ
GMV-140WL/A-X
ǃ
GMV-160WL/A-X
Product Code
CN850W0260 / CN850W0250 / CN850W0240
Part Code
Quantity
14
Rear Side Plate Sub-Assy
01314100011P
1
15
Right Connection Board
01344100003P
1
16
Current Divider
04414153
1
17
Strainer
07212121
1
18
Silencer
07245012
1
19
Condenser Sub-Assy
01154100008
1
20
Atmolysis Pipe Sub-Assy
04534100062
1
21
Cut off Valve
07330000001
1
22
Strainer
07212121
1
23
4-way Valve
43000338
1
24
Nozzle for Adding Freon
06120012
1
25
Rear Grill
01574100004
1
26
Strainer
07212121
1
27
Cut off Valve
07130239
1
28
Low Pressure Survey Valve Sub-Assy
07334100067
1
29
Inhalation Tube Sub-assy
04574100107
1
30
Strainer
07212121
1
31
Electromagnetic Valve
43000054
1
32
Discharge Tube Sub-Assy
04534100092
1
33
Coping
01264100008P
1
34
Reactor
43130192
1
35
Main Board
30226000046
1
36
Filter Board
30223000044
1
37
Electric Box Assy
26905200088
1
38
Radiator
49018000087
1
39
Terminal Board
42011221
1
40
Terminal Board
42018000026
1
41
Left Side Plate
01314100013P
1
42
Motor Support Sub-Assy
01805200244
1
43
Sensor (High Pressure)
322101032
1
44
Sensing Device
322101002
1
45
Sensor Sub-Assy
39008000061G
1
46
Magnet Coil
4304000417
1
47
Magnet Coil
4304000417
1
48
Magnet Coil
4304000417
1
Above data is subject to change without notice, pls reference the SP in global service website.
