GREE GMV5 INDOOR UNIT SERVICE MANUAL
219
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND28ZD/A-T
CM600N0350
GMV-ND36ZD/A-T
CM600N0360
GMV-ND50ZD/A-T
CM600N0320
GMV-ND56ZD/A-T
CM600N0400
Part code
Quantity
16
Guide Louver Supporter Sub-assy
0180941601
1
17
Fixed Mount
26909426R
1
18
Display Board
30294000009
1
19
Rear Side Plate Assy
01319400008
1
20
Evaporator Assy
01024100126(28)
1
01024100096(36
,
50)
21
Rotating Shaft
26909413
1
22
Connecting Rod
26909411
1
23
Rotating Shaft
26909412
1
24
Stepping Motor
1521240206
1
25
Installation Supporting Frame
01809401
1
26
Left Side Plate Sub-Assy
01319428
1
27
Electric Box Assy
01394100343
1
28
Main Board
30226000029
1
29
Electric Box Cover
01429420
1
30
Left Cover Plate
26909443
1
31
Terminal Board
42011106
1
32
Terminal Board
4201800002601
1
33
Mid-clapboard sub-assy
01249400004
1
34
Support Of Motor Bearing
01792408
2
35
O-Gasket of Bearing
76512404
2
36
Rotary Axis Sub-Assy
73018000037
2
37
Centrifugal Fan
10425200
4
38
Joint Slack
73018731(36
,
50)
2
39
Supporter
01809400024
1
40
Fan Motor
15704100001
1
41
Supporter
01809400023
1
42
Rear Connection board
01349422
1
43
Front Volute Casing
26905205
4
44
Rear Volute Casing
26905206
4
45
Remote Controller
30510589
1
46
Electric expand valve fitting
4304413203
1
47
Water Tray Assy
01289404
1
48
Top Cover Board Sub-assy
01269409
1
49
Front Grill sub-assy
01579403
2
50
Drainage Pipe Sub-assy
05235434
1
Above data is subject to change without notice, pls reference the SP in global service website.
