GREE GMV5 INDOOR UNIT SERVICE MANUAL
269
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND56ZA/A-T
CM810N1451
GMV-ND63ZA/A-T
CM810N1440
GMV-ND71ZA/A-T
CM810N1430
Part code
Quantity
1
Supporter
012060002587
2
2
Filter Sub-Assy
111001000101
1
3
Front Volute Casing
26905205
3
4
Centrifugal Fan
10425200
3
5
Rotray Axis Sub-Assy
73018020
1
6
Joint Slack
73018731
1
7
Brushless DC Motor
15704100001
1
8
Rear Volute Casing
26905206
3
9
Water Tray Assy
000069060001
1
10
Water Tray Assy
000069000112
1
11
Bottom Cover Plate Assy
000133000015
1
12
Sealplate sub-assy (drainage)
01495318
1
13
Left Side Plate Assy
01315200087
1
14
Terminal Board
4201800002601
1
15
Terminal Board
42000100000101
1
16
Main Board
30226000029
1
17
Electric Box Assy
100002004224
1
18
Electronic Expansion Valve
07334466
1
19
Strainer
0741410000601
2
20
Evaporate Assy
011001060025
1
21
Air Outlet Frame Assy
000141000026
1
22
Right Side Plate Assy
000081000032
1
23
Top Cover Board Assy
000132000026
1
24
Display Board
30296000040
1
25
Sensor Sub-assy
39004168G
1
26
Electric Expand Valve Fitting
4304413215
1
27
Corrugated Pipe
05015408
1
Above data is subject to change without notice, pls reference the SP in global service website.
