Gree GMV-ND36ZD/A-T

GREE GMV5 INDOOR UNIT SERVICE MANUAL
196
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND40PLS/A-T
CM800N3400
GMV-ND45PLS/A-T
CM800N3410
GMV-ND50PLS/A-T
CM800N3420
Part code
Quantity
16
Sealplate sub-assy (drainage)
01495315
1
17
Sealplate sub-assy (outlet)
01495316
1
18
Left Side Plate Assy
01315200087
1
19
Main Board
30226000029
1
20
Water Pump
43138000068
1
21
Water Level Switch
45020216
1
22
Electronic Expansion Valve
07334466
1
23
Strainer
0741410000601
2
24
Air Outlet Frame Assy
01374637
1
25
Cover of Air Outlet
01265331
1
26
Filter Sub-Assy
11128633
1
27
Evaporator Assy
01024100110
1
28
Water Tray Assy
01285333
1
29
Top Cover Board Assy
01265328
1
30
Choke Plug of Drain Pipe
76815214
2
31
Right Side Plate Assy
01305263
1
32
Sensor Sub-assy
39004168G
1
33
Drain Hose Sub-Assy
05232050
1
34
Display Board
30296000040
1
35
Pump Drainpipe
200070000008
1
36
Electric Expand Valve Fitting
4304413215
1
Above data is subject to change without notice, pls reference the SP in global service website.
