Gree GMV5 Compact Series Service Manual

0 119 MAINTENACE
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
No.
Name of part
Quantity
Product code
1
Coping
1
01264100014
2
Main Board ZQCD
1
30224100001
3
Filter Board ZLBCD
1
30224100002
4
Radiator TL-002 15X11
1
49010252
5
Main Board WZCD3B
1
30223000007
6
Electric Box Assy GMV-280WL/A
1
01394100069
7
Filter Board
60A/800V(DF60BA80)(Three-phase)
1
46010608
8
Terminal Board(2bit)
1
42011154
9
Terminal Board (4bit) T480C
1
42011043
10
Magnetic Ring (IV 38X13X19)
3
49010109
11
Left Side Plate
1
01314100024P
12
Front Grill
2
01574100006
13
Cabinet
1
01514100003P
14
Front Side Plate
1
01314100026P
15
Handle(apricot gray)
3
26235253
16
Axial Flow Fan (primary color)
2
10335010
17
Electromagnetic Valve
5
43000054
18
Magnet Coil
1
4300040032
19
Current Divider(Y-pipe)
1
03410101
20
Electrical Heater(Compressor)
2
765152123
21
Cut-off Valve 3/8(R410A)
1
07330000002
22
Cut-off Valve 3/4(R410A)
1
07330000001
23
Installation Plate Assy (valve)
1
01324100017
24
Compressor Gasket ZE8.639.601
6
76710247
25
Rear Side Plate
1
01314100025P
26
Balancing Oil Tube Assy
1
04224100203
27
Compressor and fittings
QXAS-D32zX050
2
00204100005
28
Pressure Protect Switch(with out going
line)
1
4602001535
29
Electric Expand Valve Fitting
1
43044100059
30
Discharge Charge Valve
1
07334100002
