Gree GMV5 Compact Series Service Manual

0 75 MAINTENACE
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
Vacuumization
A8
Test module
SS
Only the outdoor unit displays the code
Note: Last ten protection shutdown and protection limited frequency reduction can be searched through the
debugging controller.
1.1.4 The meaning of indicator light flicker for mainboard and drive board.
Flicker Tmies
Yellow
Red
Green
1
Compressor1 ON
Outdoor unit is always at
ON status
Drive board
2
Compressor2 ON
Reservation
Debug board
3
Overcurrent for IPM1
Oil return
Testing online
4
Overcurrent for IPM1
Defrosting
PC monitor
5
IPM1 protection
Limited frequency reduction
for IPM temperature
protection
Indoor unit 1
6
IPM2 protection
Limited frequency reduction
for pfc temperature
protection
Indoor unit 2
7
PFC overcurrent
Limited frequency reduction
for AC current protection
Indoor unit 3
8
PFC protection
Limited frequency reduction
for power protection
Indoor unit 4
9
Low voltage protection
Limited frequency reduction
for discharge temperature
protection
Indoor unit 5
10
High voltage protection
Limited frequency reduction
for low pressure protection
Indoor unit 6
11
System low pressure
protection
Limited frequency reduction
for high pressure protection
Indoor unit 7
12
System high pressure
protection
Malfunction of discharge
temperature sensor of
compressor 1
Indoor unit 8
13
High-pressure switch
protection
Malfunction of outdoor
ambient temperature sensor
Indoor unit 9
14
Drive charging circuit
malfunction of compressor
Malfunction of outdoor tube
temperature sensor
Indoor unit 10
15
AC current protection
Malfunction of suction
temperature sensor
Indoor unit 11
16
Malfunction of EEPROM
chip
Malfunction of indoor coil
inlet temperature sensor
Indoor unit 12
17
Demagnetization protection
for compressor1
Malfunction of temperature
sensor for subcooler
Indoor unit 13
