window or wall
discharge pipe
cooled air
Heated air
Cooling region
Flow direction
of cooled air
Mobile AC
Heat air
1.5 ~ 2m
60 ~ 70
(Sector cooling area)
When only used as dehumidifier, remember to take off heat
discharge pipe from unit and install it onto unit when the unit is
used as air conditioner. Since partial indoor air will be heated
as heat air and discharged to outside by discharge pipe after
cycling then outdoor air will enter to maintain balance air
pressure, thus the air conditioner will only lower temperature
of partial regional air of indoor room instead of turning entire
indoor air to a lower temperature.
Usage Location
1. Where room area is smaller than 15m , and wall (or building) has well heat insulation effect.
As shown in following figure, if unit is in shown location, the cooling effect will be better.
2. If room area is larger than 20m , for example workshop or factory, the unit can only offer cooled
air to partial area (as shown in following figure), and people in this area can enjoy better cooling
effect.
Room
2
2
- 2-
