Gree GUD50T/A-T Service Manual

GREE U-Match 5 SERIES UNIT SERVICE MANUAL
129
No.
Material name
Finished Product Code
Quantity
1
Front Grill
22415010
1
2
Front Panel
01535013
1
3
Axial Flow Fan
10335008
1
4
Fan Motor
1501506402
1
5
Drainage Joint
06123401
1
6
Drainage hole Cap
76713033
1
7
Drainage hole Cap
76713068
1
8
Drainage hole Cap
06813401
1
9
Base Plate Sub-assay
01205816
1
10
Compressor and Fittings
00900100019501
1
11
Compressor Gasket
009012000004
3
12
4 Way Valve Coil
4300040087
1
13
Silencer1
07243050
1
14
Silencer2
07243049
1
15
4-way Valve
430004032
1
16
Cut off Valve
07133844
1
17
Strainer
0721302608
1
18
Cut off Valve
071302391
1
19
Electronic Expansion Valve
072009000004
1
20
Valve Support Sub-assay
01705046
1
21
Strainer
07225088
1
22
Right Side Plate
0130509001
1
23
Handle
2623525404
1
24
Rear Grill
01475020
1
25
Clapboard Sub-assay
01235081
1
26
Condenser Assay
011002000177
1
27
Electric Expand Valve Fitting
43000344
1
28
4-way Valve Assay
030152060086
1
29
Condenser Support Plate
01795031
1
30
Terminal Board
422000000007
1
31
Terminal Board
42200000002402
1
32
Main Board
300027060157
1
33
Radiator
4901521502
1
34
Top Cover Sub-assay
000051000017
1
35
Electric Box Assay
100002061278
1
36
Motor Support Sub-assay
01705067
1
37
Handle
26233053
1
38
Left Side Plate
01305093
1
39
Temperature Sensor
3900007201
1
40
Compressor Overload Protector(External)
00180030
1
41
Compressor Overload Protector(External)
00183032
1
42
Compressor Overload Protector(External)
00183031
1
