GREE U-Match 5 SERIES UNIT SERVICE MANUAL
114
4.5.2 Removal of IDU Major Components
4.5.2.1 Cassette Type Unit
Note: Before removing the motor, power must be cut off.
1. Remove the front panel.
●Turn off the power supply of
indoor unit.
●Push the 4 corner plates in the
directions shown by the arrows.
●Loosen the screws and
remove the front panel.
2. Remove the cover of
electric box and the clamp
of power cord.
●Remove the motor wire and
water pump of the electric box.
4. Remove the water tray.
●Loosen the screws in the 4
corners and then remove the
water tray.
To Next Page
