Gree GUD50T/A-T Service Manual

GREE U-Match 5 SERIES UNIT SERVICE MANUAL
33
(2) Filtering Board
No.
Printing
Interface
No.
Printing
Interface
1
AC-L
Power input live wire terminal
5
N-OUT
Power output neutral wire terminal
(reserved)
2
AC-N
Power input neutral wire terminal
6
N-OUT
Power output neutral wire terminal
3
E1
Filtering board ground wire terminal
7
L-OUT
Power output live wire terminal
4
E2
Filtering board grounding hole
(reserved)
(3) Power board
No.
Printing
Interface
No.
Printing
Interface
1
L1
Power live wire terminal (reserved)
4
J1
+28V terminal (reserved)
2
N1
Power neutral wire terminal
(reserved)
5
PWR2
Drive power supply terminal
3
PWR1
DC busbar terminal
6
J2
+8V terminal (reserved)
1
⑩
2
⑩
3
⑩
4
⑩
5
⑩
6
⑩
7
⑩
1
1
⑩
2
⑩
3
⑩
4
⑩
5
⑩
6
⑩
