GREE U-Match 5 SERIES UNIT SERVICE MANUAL
103
Note: Before removing the front panel, make sure power is cut off.
3. Remove the front panel.
●Unscrew the screws that
connect the front panel to the
middle insulating board and
screws around the front panel.
4. Remove the right side plate.
●Unscrew the screws that
connect the right side plate to the
electric box and the screws
around the right side plate.
5. Install the right side plate
●Screw up the screws around the
right side plate. Be careful to
handle well the clasps at the
bottom of the right side plate.
6. Install the front panel.
●Install the front panel by
mounting on 6 clasps on its both
sides. Please note that there is
one screw on the lower right side.
To Next Page
