Technical Information
Service Manual
Model
4LIV24HP230V1A
Product Code
CB574002500
Power
Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 22000
Heating Capacity Btu/h 24000
Cooling Power Input W 1896
Heating Power Input W 2051
Cooling Current A 8.5
Heating Current A 9.5
Rated Input W 2400
Rated Current A 12
EER (Btu/h)/W 11.6
COP (Btu/h)/W 11.7
SEER 18(SEER) 18(SEER2)
HSPF 10(HSPF) 8.5(HSPF2)
Air Flow Volume CFM 677/589/559/500/471/441/412
Dehumidifying Volume Pint/h 5.28
Application Area yd
2
28-41
Indoor Unit
Indoor Unit Model
4LIV24HP230V1AH
Product Code of Indoor Unit
CB574N02500
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Ф111.5X830
Cooling Speed r/min 1350/1200/1100/1000/950/900/850
Heating Speed r/min 1350/1200/1100/1000/950/900/850
Fan Motor Power Output W 45
Fan Motor RLA A 0.45
Fan Motor Capacitor μF /
Heater Power Input W /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф7
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm 840X25.4X381
Swing Motor Model MP35CP
Swing Motor Power Output W 2.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling: 51/47/45/42/40/38/36
Heating: 52/48/45/42/40/38/37
Sound Power Level dB (A)
Cooling: 61/57/55/52/50/48/46
Heating: 62/58/55/52/50/48/47
Dimension (WXHXD) inch 42 7/16 X13 7/64 X9 11/16
Package Carton Dimension (LXWXH) inch 44 13/32 X15 63/64X12 23/32
Package Dimension (LXWXH) inch 44 39/64/32X16 19/64X13 7/64
Net Weight Ib 33.1
Gross Weight Ib 39.7

Gree GWC09ATCXB-D3DNA1A/I Specifications

General

Brand	Gree
Model	GWC09ATCXB-D3DNA1A/I
Category	Air Conditioner
Language	English
