14
Technical Information
Service Manual
Outdoor
Unit
Outdoor Unit Model
4LIV24HP230V1AO
Product Code of Outdoor Unit CB444W15900
Compressor Manufacturer
ZHUHAI LANDA COMPRESSOR
CO. LTD.
Compressor Model FTz-SM151AXBD
Compressor Oil FW68DA or equivalent
Compressor Type Rotary
Compressor LRA. A 35.00
Compressor RLA A 10.39
Compressor Power Input W 1330
Compressor Overload Protector HPC 115/95U1 KSD115
℃
Fan Type Axial-ow
Fan Diameter mm 520
Fan Motor Speed rpm 880
Fan Motor Power Output W 60
Fan Motor RLA A 0.73
Fan Motor Capacitor μF 3.5
Outdoor Unit Air Flow Volume CFM 1883
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Ф7
Condenser Rows-n Gap mm 2-1.4
Condenser Coil Length (LXDXW) mm 839X38.1X616
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Maximum Allowable Pressure MPa 4.3
Set Temperature Range
º
F 61~86
Cooling Operation Ambient Temperature Range
º
F -0.4~122
Heating Operation Ambient Temperature Range
º
F 19.4~75.2
Throttling Method Electron expansion valve
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Sound Pressure Level dB (A) 57
Sound Power Level dB (A) 67
Dimension (WXHXD) inch 37 23/32X25 63/64X15 53/64
Dimension of Carton Box (LXWXH) inch 40 33/64X17 53/64X28 5/32
Dimension of Package(LXWXH) inch 40 5/8X17 61/64X29 1/64
Net Weight lb 97
Gross Weight lb 106.9
Refrigerant R410A
Refrigerant Charge oz 52.9
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.5
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 5/8
Max. Height Distance ft 32.8
Max. Length Distance ft 82.0
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
