135
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWC12QC-D3DND8C/I GWH12QC-D3DND8A/I
Product Code CB459N06700 CB459N07000
1 Front Panel 200003000003S 200003000003S 1
2 Filter Sub-Assy 1112246803 1112246803 2
3 Display Board 300001000035 300001000035 1
4 Front Case Assy 00000200045 00000200045 1
5 Guide Louver 1051293101 1051293101 1
6 Helicoid Tongue 26112436 26112436 1
7 Left Axile Bush 10512037 10512037 1
8 Rear Case assy 00000100093 00000100093 1
9 Drainage Hose 05230014 05230014 1
10 Ring of Bearing 26152022 26152022 1
11 O-Gasket sub-assy of Bearing 76512051 76512051 1
12 Evaporator Supper 24212179 24212179 1
13 Cold Plasma Generator / / /
14 Evaporator Assy 011001060162 011001060162 1
15 Wall Mounting Frame 01252484 01252484 1
16 Cross Flow Fan 10352056 10352056 1
17 Fan Motor 1501214607 1501214607 1
18 Connecting pipe clamp 2611216401 2611216401 1
19 Rubber Plug (Water Tray) 76712012 76712012 1
20 Stepping Motor 1521210710 1521210710 1
21 Crank 73012005 73012005 1
22 Electric Box Assy 100002067685 100002067684 1
23 Axile Bush 10542036 10542036 1
24 Terminal Board 42011233 42011233 1
25 Jumper 4202021914 4202021914 1
26 Main Board 300002061140 300002061141 1
27 Screw Cover 2425203001 2425203001 1
28 Electric Box Cover Sub-Assy 0140206501 0140206501 1
29 Shield Cover of Electric Box Cover 01592150 01592150 1
30 Electric Box Cover 2011220701 2011220701 1
31 Power Cord / / /
32 Connecting Cable / / /
33 Remote Controller 305001060022 305001060022 1
34 Detecting plate(WIFI) 30070077 30070077 1
To Next Page
