4
Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model GWH09QB-D3DNC6L GWH12QC-D3DNC6L
Product Code CB443004600 CB443004700
Power Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) Btu/h 9200(909~9600) 12100(3753~12500)
Heating Capacity(Min~Max) Btu/h 10000(3100~12000) 12900(3924~14000)
Cooling Power Input(Min~Max) W 867(375~1300) 1150(410~1350)
Heating Power Input(Min~Max) W 894(300~1350) 1250(380~1500)
Cooling Power Current A 4.0 5.1
Heating Power Current A 3.8 5.55
Rated Input W 1350 1500
Rated Current A 5.8 6.88
Air Flow Volume(SH/H/M/L) CFM 318/288/241/171 400/318/253/194
Dehumidifying Volume Pint/h 1.69 2.96
EER (Btu/h)/W 10.59 10.43
COP (Btu/h)/W 11.18 10.4
SEER 18.50 18.50
HSPF 10.20 9.20
Application Area yd
2
19.14-28.70 19.14-28.70
Indoor Unit
Model of indoor unit GWH09QB-D3DNC6L/I GWH12QC-D3DNC6L/I
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ3 55/64X22 5/6 Φ3 7/8X25
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1050/750 1350/1200/1000/800
Fan Motor Heating Speed(SH/H/M/L) r/min 1350/1200/1050/850 1350/1200/1000/900
Output of Fan Motor W 20 20
Fan Motor RLA A 0.22 0.31
Fan Motor Capacitor μF 1 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ13/64 Φ3/16
Row-n Gap inch 2-1/16 2-1/16
Coil Length (LXDXW) inch 23X7/8X10 8/16 25X7/8X12 1/16
Swing Motor Model MP24AA MP24BA
Output of Swing Motor W 1.5
1.5
Fuse A 3.15 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 43/38/34/28/- 43/39/35/29
Sound Power Level(SH/H/M/L) dB (A) 53/49/45/39/- 53/49/45/39
Dimension (WXHXD) inch 31 7/64X10 5/6X7 7/8 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 34X10 35/64X13 55/64 36 1/8X11X14 5/16
Dimension of Package (LXWXH) inch 34X10 21/32X14 29/64 36 1/4X11X15
Net Weight Ib 20.9 23.15
Gross Weight Ib 25.4 27.56
