5
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit GWH09QB-D3DNC6L/O GWH12QC-D3DNC6L/O
Outdoor Unit Product Code CB443W04600 CB443W04700
Compressor Manufacturer/Trademark
ZHUHAI GREE DAIKIN DEVICE
CO.,LTD
ZHUHAI LANDA COMPRESSOR
CO,LTD.
Compressor Model QXA-B102zE190 QXA-B102zE190
Compressor Oil RB68EP RB68EP
Compressor Type Rotary Rotary
Compressor Locked Rotor Amp (L.R.A) A / /
Compressor RLA A 6.6 6.6
Compressor Power Input W 1020 1020
Overload Protector
1NT11L-6233 or HPC115/95U1 or
KSD115
1NT11L-6233 or HPC115/95U1 or
KSD115
Throttling Method Electric Expansion Valve Sub-Assy Electron expansion valve
Operation temp ºF 60.8~86 60.8~86
Ambient temp (cooling) ºF 0~115 0~115
Ambient temp (heating) ºF -13~75 -4~75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32 Φ5/16
Rows-n Gap inch 1-1/18 2-1/16
Coil Length (LXDXW) inch 28X3/4X20 28X1 1/2X20
Fan Motor Speed rpm 900 900
Output of Fan Motor W 30 30
Fan Motor RLA A 0.36 0.37
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit CFM 942 1600
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ15 3/4 Φ15 3/4
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 550 550
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 240 240
Sound Pressure Level (H/M/L) dB (A) 52/-/- 53/-/-
Sound Power Level (H/M/L) dB (A) 62/-/- 63/-/-
Dimension (WXHXD) inch 30 9/16X21 1/4X12 5/8 30 9/16X21 1/4X12 5/8
Dimension of Carton Box (LXWXH) inch 32 9/32X13 63/64X22 27/32
32 9/32X13 63/64X22 27/32
Dimension of Package (LXWXH) inch 32 13/32X14 3/32X23 27/64 32 13/32X14 3/32X23 27/64
Net Weight Ib 63.9 69.45
Gross Weight Ib 69.5 74.96
Refrigerant R410A R410A
Refrigerant Charge oz 24.7 31.8
Connection
Pipe
Length ft 24.6 24.6
Gas Additional Charge oz/ft 0.2 0.2
Outer Diameter Liquid Pipe inch Φ1/4 Φ1/4
Outer Diameter Gas Pipe inch Φ3/8 Φ3/8
Max Distance Height ft 60 60
Max Distance Length ft 100 100
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
