Gree GWC18AFD-D3DNA1A/O

171
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWC18AFD-D3DNA1A/O
Product Code CB348W04700
1 Front Grill 016004060004 1
2 Front Panel 000003060115 1
3 Axial Flow Fan 10333014 1
4 Chassis Sub-assy 209058060167P 1
5 Clapboard Assy 01233168 1
6 Compressor and Fittings 009001060066 1
7 Inhalation Tube Sub-assy 030010060613 1
8 Discharge Tube Sub-assy 035008061392 1
9 Valve Support Assy 01713115P 1
10 Cut off Valve Assy 1/2 07133774 1
11 Cut off Valve Sub-Assy 07335708 1
12 Right Side Plate 01303244P 1
13 Valve Cover 22243005 1
14 Cable Cross Plate Sub-assy 02123015 1
15 Rear Grill 01473060 1
16 Condenser Assy 011002060859 1
17 Coping 000051060084 1
18 Motor Support Sub-Assy 0170339802 1
19 Supporting Board(Condenser) 01795028 1
20 Fan Motor 1501506402 1
21 Left Side Plate 01303169P 1
22 Electric Box Assy 100002066688 1
23 Terminal Board 42200006001401 1
24 Electric Box 100002066688 1
25 Radiator 49013060 1
26 Main Board 300027060829 1
27 Temperature Sensor 3900030902 1
