173
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWH24QE-D3DNB2R/O
Product Code CB432W21500
1 Axial Flow Fan 10333023 1
2 Fan Motor 1501506406 1
3 Electric Box Assy 100002067147 1
4 Electric Box 20113027 1
5 Radiator 49013060 1
6 Main Board 300027060877 1
7 Electric Box Cover 20123028 1
8 Terminal Board 42200006001401 1
9 Handle 26233014 1
10 Left Side Plate 01303025 1
11 Coping 01253105 1
12 Motor Support 01703245 1
13 Clapboard Sub-Assy 017021000063 1
14 Condenser Assy 01100206086201 1
15 4-Way Valve Assy 030152060381 1
16 Rear Grill 016001000023 1
17 Electric Expand Valve Fitting 4300034419 1
18 Right Side Plate-Assy 00008100002101 1
19 Handle 26233014 1
20 Valve Cover 22243015 1
21 Cut-off valve 5/8(N) 07133844 1
22 Electronic Expansion Valve assy 43005016 1
23 Valve Support Block 26113017 1
24 Compressor and Fittings 009001060387 1
25 Chassis 012008060074 1
26 Drainage Joint 26113009 1
27 Cabinet 0143307201 1
28 Front Grill 01473008 1
29 Electric Heater 320004060086 1
