29
Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Model of Outdoor Unit GWC24QE-D3DNB2R/O GWH24QE-D3DNB2R/O
Outdoor Unit Product Code CB432W21600 CB432W21500
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO.,LTD
ZHUHAI LANDA COMPRESSOR
CO.,LTD
Compressor Model QXFS-B181zX030AA QXFS-B181zX030AA
Compressor Oil FW68DA or equivalent FW68DA or equivalent
Compressor Type Twin Rotary Twin Rotary
Compressor Locked Rotor Amp (L.R.A) A 25.00 25.00
Compressor RLA A 13.00 13.00
Compressor Power Input W 1635 1635
Overload Protector
1NT11L-6233 KSD115
℃
HPC
115/95
1NT11L-6233 KSD115
℃
HPC
115/95
Throttling Method Electron expansion valve Electron expansion valve
Operation temp ºF 61~86 61~86
Ambient temp (cooling) ºF 0~115 0~115
Ambient temp (heating) ºF / -4~75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ17/64 Φ17/64
Rows-n Gap inch 2-1/16 2-1/16
Coil Length (LXDXW) inch 31 21/32X1 1/2X24 1/4 31 21/32X1 1/2X24 1/4
Fan Motor Speed rpm 800 800
Output of Fan Motor W 60 60
Fan Motor RLA A 0.65 0.65
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit CFM 1883 1883
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ20 15/32 Φ20 15/32
Defrosting Method / /
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 550 550
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 240 240
Sound Pressure Level (H/M/L) dB (A) 59/-/- 59/-/-
Sound Power Level (H/M/L) dB (A) 69/-/- 69/-/-
Dimension (WXHXD) inch 35 29/32X25 7/16
X14 11/16 35 29/32X25 7/16X14 11/16
Dimension of Carton Box (LXWXH) inch 37 51/64×16 5/8×26 49/64 37 51/64×16 5/8×26 49/64
Dimension of Package (LXWXH) inch 37 29/32×16 3/16×27 9/16 37 29/32×16 3/16×27 9/16
Net Weight Ib 94.8 97.0
Gross Weight Ib 101.4 103.6
Refrigerant R410A R410A
Refrigerant Charge oz 52.9 52.9
Connection
Pipe
Length ft 24.6 24.6
Gas Additional Charge oz/ft 0.2 0.5
Outer Diameter Liquid Pipe inch Φ1/4 Φ1/4
Outer Diameter Gas Pipe inch Φ5/8 Φ5/8
Max Distance Height ft 32.8 32.8
Max Distance Length ft 82 82
Note:The connection pipe applies metric diameter.
