Model of Outdoor Unit GWH09QB-D3DNB2J/O
Outdoor Unit Product Code CB432W21800
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD.
Compressor Model QXF-A079zE190A
Compressor Oil FW68DA or equivalent
Compressor Type Rotary
Compressor Locked Rotor Amp (L.R.A) A 18
Compressor RLA A 6.6
Compressor Power Input W 790
Overload Protector HPC115/95U1 KSD115
℃
Throttling Method Capillary
Operation temp ºF 61~86
Ambient temp (cooling) ºF 0~115
Ambient temp (heating) ºF -4~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32
Rows-n Gap inch 1-1/16
Coil Length (LXDXW) inch 27 61/64X3/4X20
Fan Motor Speed rpm 900
Output of Fan Motor W 30
Fan Motor RLA A 0.37
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 942
Fan Type Axial-ow
Fan Diameter inch Φ15 3/4
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 550
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 240
Sound Pressure Level (H/M/L) dB (A) 50/-/-
Sound Power Level (H/M/L) dB (A) 60/-/-
Dimension (WXHXD) inch 30 9/16X21 1/4X12 5/8
Dimension of Carton Box (LXWXH) inch 32 9/32X13 63/64X22 27/32
Dimension of Package (LXWXH) inch 32 13/32X14 3/32X23 27/64
Net Weight Ib 58.4
Gross Weight Ib 63.9
Refrigerant R410A
Refrigerant Charge oz 24
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch Φ1/4
Outer Diameter Gas Pipe inch Φ3/8
Max Distance Height ft 32.8
Max Distance Length ft 49.2
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
