3
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor Unit
Outdoor Unit Model GWC18MC-D3DNA3D/O
Outdoor Unit Product Code CB171W06800
Compressor Manufacturer
MITSUBISHI ELECTRIC (GUANGZHOU)
COMPRESSOR CO.,LTD
Compressor Model SNB130FGAMC
Compressor Oil FV50S/PVE
Compressor Type Rotary
Compressor LRA. A 13.8
Compressor RLA A 4.1
Compressor Power Input W 1200
Compressor Overload Protector INT11L-6578
Throttling Method Electron expansion valve
Set Temperature Range °F 61~86
Cooling Operation Ambient Temperature Range °F 19.4~109
Heating Operation Ambient Temperature Range °F /
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter inch Φ2/7
Condenser Rows-n Gap inch 2-1/18
Condenser Coil Length (LXDXW) inch 33X1 1/2X26
Fan Motor Speed rpm 800
Fan Motor Power Output W 60
Fan Motor RLA A 0.28
Fan Motor Capacitor μF /
Outdoor Unit Air Flow Volume CFM 1883
Fan Type Axial-ow
Fan Diameter inch 20 1/2
Defrosting Method /
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating Pressure for the
Discharge Side
PSIG 550
Permissible Excessive Operating Pressure for the
Suction Side
PSIG 450
Sound Pressure Level (H/M/L) dB (A) 56/-/-
Sound Power Level (H/M/L) dB (A) 66/-/-
Dimension (WXHXD) inch 37 3/5X27 5/9X15 3/5
Dimension of Carton Box (LXWXH) inch 40 2/5X18X29
Dimension of Package (LXWXH) inch 40 1/2X18X29 1/2
Net Weight lb 99.2
Gross Weight lb 110.3
Refrigerant R410A
Refrigerant Charge oz 24 3/5
Connection
Pipe
Connection Pipe Length ft 24 3/5
Connection Pipe Gas Additional Charge oz/ft. 0.2
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 1/2
Max Distance Height ft 32.8
Max Distance Length ft 82
Note: The connection pipe applies metric diameter.
