Installation and Maintenance
Service Manual
NO.
Description
Part Code
QtyGWC18MC-D3DNA3F/I GWH18MC-D3DNA3D/I
Product Code CB171N08800 CB171N08900
1 Front Panel Assy 20012260 20012260 1
2 Filter Sub-Assy 11122089 1112208901 2
3 Screw Cover 24252016 24252016 3
4 Bafe Plate 26112228 26112228 1
5 Front Case Sub-assy 20022172 20012288 1
6 Air Louver 1 10512708 10512708 1
7 Air Louver 2 10512709 10512709 1
8 Helicoid Tongue 26112238 26112238 1
9 Left Axile Bush 10512037 10512037 1
10 Rear Case assy 22202128 22202128 1
11 Rubber Plug (Water Tray) 76712012 76712012 1
12 Ring of Bearing 26152022 26152022 1
13 O-Gasket sub-assy of Bearing 76512051 76512051 1
14 Cross Flow Fan 10352019 10352019 1
15 Evaporator Support 24212133 24212133 1
16 Evaporator Assy 01002575 01002575 1
17 Wall Mounting Frame 01252218 01252218 1
18 Motor Press Plate 26112178 26112178 1
19 Fan Motor 1501211601 1501211601 1
20 Pipe Clamp 26112164 26112164 1
21 Drainage Hose 05230014 05230014 1
22 Step Motor 15012086 15012086 1
23 Crank 10582070 10582070 1
24 Display Board 30565038 30565038 1
25 Mesh Enclosure(Air Outlet) 01472015 01472015 1
26 Guide Louver 10512115 10512115 1
27 Axile Bush 10542036 10542008 1
28 Electric Box 20102000451 20102000450 1
29 Terminal Board 42011233 42011233 1
30 Electric Box Cover2 20112081 20112081 1
31 Main Board 30138000224 30138000222 1
32 Shield Cover of Electric Box 01592092 01592092 1
33 Electric Box Cover1 20122154 20122128 1
34 Jumper 4202300109 4202300109 1
35 Capacitor CBB61 33010043 33010043 1
36 Electric Box Assy 20302427 2020210511 1
37 Ambient Temperature Sensor 390000453 390000453 1
38 Temperature Sensor 390000591 390000591 1
39 Remote Controller 305100482 305100482 1
Above data is subject to change without notice.
