76
Installation and Maintenance
Service Manual
NO.
Description
Part Code
QtyGWH18MC-D3DNA8F/I
Product Code CB173N04900
1 Front Panel Assy 20012285 1
2 Filter Sub-Assy 1112208901 2
3 Screw Cover 24252016 3
4 Front Case Sub-assy 20022205 1
5 Air Louver 1 10512708 1
6 Air Louver 2 10512709 1
7 Helicoid Tongue 26112238 1
8 Left Axile Bush 10512037 1
9 Rear Case assy 22202128 1
10 Rubber Plug (Water Tray) 76712012 1
11 Ring of Bearing 26152022 1
12 O-Gasket sub-assy of Bearing 7651205102 1
13 Cross Flow Fan 10352019 1
14 Evaporator Support 24212133 1
15 Evaporator Assy 01002575 1
16 Wall Mounting Frame 01252218 1
17 Motor Press Plate 26112494 1
18 Fan Motor 1501214601 1
19 Connecting pipe clamp 26112164 1
20 Drainage Hose 05230014 1
21 SteppingMotor 15012086 1
22 Crank 10582070 1
23 Mesh Enclosure(Air Outlet) 01472015 1
24 Guide Louver 10512115 1
25 Axile Bush 10542036 1
26 Transformer 43110257 1
27 Electric Box 20112108 1
28 Terminal Board 42011233 1
29 Electric Box Cover2 20112081 1
30 Display Board 3056504301 1
31 Main Board 30138061 1
32 Shield Cover of Electric Box 01592092 1
33 Electric Box Cover1 20122154 1
34 Jumper 4202300102 1
35 Capacitor CBB61 33010043 1
36 Lower Shield of Electric Box 01592091 1
37 Electric Box Assy 2020211440 1
38 Ambient Temperature Sensor 390000451 1
39 Tube Sensor 390000595 1
40 Remote Controller 30510048 1
Above data is subject to change without notice.
