83
Installation and Maintenance
Service Manual
NO.
Description
Part Code
QtyGWC18MC-D3DNA3D/O
Product Code CB171W06800
1 Rear Grill 01473043 1
2 Cabinet 01433047P 1
3 Axial Flow Fan 10335008 1
4 Fan Motor 1501506402 1
5 Chassis Sub-assy 02803062P 1
6 Compressor and Fittings 00105241 1
7 Compressor Gasket 76715021 3
8 Inhalation Tube 03723930 1
9 Discharge Tube Sub-assy 03833122 1
10 Electric Expansion Valve Sub-Assy 07133681 1
11 Valve Support Assy 01715010P 1
12 Cut off Valve Sub-Assy 07133058 1
13 Valve Cover 22245002 1
14 Retaining Plate 02115006P 1
15 Handle assy 02113109 1
16 Right Side Plate 0130509403P 1
17 Cut off Valve Sub-Assy 07133210 1
18 Clapboard Assy 01233153 1
19 Condenser Assy 01163512 1
20 Front Grill 01473049 1
21 Wiring Clamp 26115004 1
22 Top Cover 01255005P 1
23 Motor Support Sub-Assy 01705036 1
24 Supporting Board(Condenser) 01795010 1
25 Left Side Plate 01305093P 1
26 Left Handle 26235401 1
27 Electric Box Assy 02603938 1
28 Main Board 30148249 1
29 Radiator 49010252 1
30 Electric Box 20113027 1
31 Wire Clamp 71010003 1
32 Wire Clamp 71010102 1
33 Terminal Board 42010255 1
34 Temperature Sensor 39000072 1
35 Temperature Sensor 3900030901 1
36 Insulated Board (Cover of Electric Box) 20113003 1
Above data is subject to change without notice.
