87
Installation and Maintenance
Service Manual
NO.
Description
Part Code
QtyGWH18MC-D3DNA3D/O(electric heating band)
Product Code CB171W04701
1 Front Grill 01473049 1
2 Cabinet 01433047P 1
3 Axial Flow Fan 10335008 1
4 Drainage Plug 06813401 3
5 Fan Motor 1501506402 1
6 Electrical Heater (Chassis) 765100045 1
7 Chassis Sub-assy 02803083P 1
8 Drainage Connecter 06123401 1
9 Gas-liquid Separator Assy 07225017 1
10 Compressor and Fittings 00105241 1
11 4-Way Valve Assy 03123891 1
12 Electric Expansion Valve Sub-Assy 07133681 1
13 Valve Support Assy 01715010P 1
14 Cut off Valve Sub-Assy 07133210 1
15 Valve Cover 22245002 1
16 Retaining Plate 02115006P 1
17 Handle assy 02113109 1
18 Right Side Plate 0130509403P 1
19 Cut off Valve Sub-Assy 07133058 1
20 Magnet Coil 4300040033 1
21 Clapboard Assy 0123315301 1
22 Condenser Assy 01163487 1
23 Rear Grill 01473043 1
24 Wiring Clamp 26115004 1
25 Top Cover 01255005P 1
26 Motor Support Sub-Assy 01705036 1
27 Supporting Board(Condenser) 01795010 1
28 Left Side Plate 01305093P 1
29 Left Handle 26235401 1
30 Electric Box Assy 0260393702 1
31 Main Board 30148496 1
32 Radiator 49010252 1
33 Electric Box 20113027 1
34 Wire Clamp 71010003 1
35 Wire Clamp 71010102 1
36 Terminal Board 42010255 1
37 Temperature Sensor 39000072 1
38 Temperature Sensor 3900030901 1
39 Insulated Board (Cover of Electric Box) 20113003 1
Above data is subject to change without notice.
