Installation and Maintenance
Service Manual
NO.
Description
Part Code
QtyGWH24MD-D3DNA3D/O
GWH24MD-D3DNA3D/O(electric
heating band)
Product Code CB171W07000 CB171W07001
1 Front Grill 01473050 01473050 1
2 Fan Motor 1501506205 1501506205 1
3 Capacitor CBB61 33010011 33010011 1
4 Radiator 49010252 49010252 1
5 Main Board 30148256 30148256 1
6 Electric Box Assy 02603939 02603939 1
7 Terminal Board 42010255 42010255 1
8 Left Handle 2623540103 2623540103 2
9 Left Side Plate 01305043P 01305043P 1
10 Top Cover 01255006P 01255006P 1
11 Motor Support Sub-Assy 01705025 01705025 1
12 Condenser Support Plate 01175092 01175092 1
13 Clapboard Assy 01233164 01233164 1
14 Condenser Assy 01163427 01163427 1
15 Rear Grill 01475013 01475013 1
16 Wiring Clamp 26115004 26115004 1
17 Temperature Sensor 39000072 39000072 1
18 Right Side Plate 0130504402P 0130504402P 1
19 Handle assy 02113109 02113109 1
20 Retaining Plate 02115006P 02115006P 1
21 Cut off Valve 07133157 07133157 1
22 Valve Cover 22245003 22245003 1
23 Valve Support Sub-Assy 0171501201P 0171501201P 1
24 Bafe(Valve Support) 01365435P 01365435P 1
25 Cut off Valve Sub-Assy 07135072 07135072 1
26 Electric Expand Valve Fitting 4300876705 4300876705 1
27 4-Way Valve Assy 03123863 03123863 1
28 Magnet Coil 4300040045 4300040045 1
29 Compressor and Fittings 00103873 00103873 1
30 Drainage Connecter 06123401 06123401 1
31 Chassis Sub-assy 02803080P 02803080P 1
32 Drainage Plug 06123401 06123401 3
33 Axial Flow Fan 10335014 10335014 1
34 Front Side Plate 01303249P 01303249P 1
35 Cabinet 0143500401P 0143500401P 1
36 Electrical Heater (Chassis) / 7651000411 1
Above data is subject to change without notice.
