Technical Information
Service Manual
Model GWH07AAA-K3NNA5A
Product Code CA488000100
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Indoor
Cooling Capacity W 2200
Heating Capacity W 2300
Cooling Power Input W 685
Heating Power Input W 637
Cooling Power Current A 3.5
Heating Power Current A 3.2
Rated Input W 1050
Rated Current A 5.5
Air Flow Volume(SH/H/M/L/SL) m
3
/h 470/420/370/250/-
Dehumidifying Volume L/h 0.6
EER W/W 3.21
COP W/W 3.61
SEER W/W /
HSPF W/W /
Application Area m
2
10-16
Indoor Unit
Model of Indoor Unit GWH07AAA-K3NNA5A/I
Product Code of Indoor Unit CA488N00100
Fan Type Cross-ow
Diameter Length(DXL) mm Φ92X505
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1300/1200/1100/850/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min 1200/1100/1000/900/-
Output of Fan Motor W 10
Fan Motor RLA A 0.15
Fan Motor Capacitor μF 1
Input of Heater W /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7.94
Row-n Gap mm 1-1.2
Coil Length (LXDXW) mm 508X19.05X254
Swing Motor Model MP24AN
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) 40/38/35/27/-
Sound Power Level (SH/H/M/L/SL) dB (A) 50/48/45/37/-
Dimension (WXHXD) mm 698X250X185
Dimension of Carton Box (LXWXH) mm 742X306X244
Dimension of Package (LXWXH) mm 747X322X255
Net Weight kg 7.5
Gross Weight kg 8.5
