Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Model of Outdoor Unit GWH07AAA-K3NNA1A/O
Product Code of Outdoor Unit CA115W13600
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO.,LTD
Compressor Model QXA-A081A130A
Compressor Oil RB68EP/FVC68D/FV50S
Compressor Type Rotary
L.R.A. A 15
Compressor RLA A 3.25
Compressor Power Input W 680
Overload Protector UP3-MC0
（
L
）
Throttling Method Capillary
Operation Temp
o
C 16~30
Ambient Temp (Cooling)
o
C 18~43
Ambient Temp (Heating)
o
C -7~24
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7.94
Rows-n Gap mm 1-1.4
Coil Length (LXDXW)
mm 658.3X19.05X396
Fan Motor Speed rpm 320
Output of Fan Motor W 20
Fan Motor RLA A 0.25
Fan Motor Capacitor μF 1.5
Air Flow Volume of Outdoor Unit m
3
/h 1200
Fan Type Axial-ow
Fan Diameter mm Φ320
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 49/-/-
Sound Power Level (H/M/L) dB (A) 59/-/-
Dimension (WXHXD) mm 720X428X310
Dimension of Carton Box (LXWXH) mm 765X350X475
Dimension of Package (LXWXH) mm 768X353X490
Net Weight kg 22
Gross Weight kg 24
Refrigerant R410A
Refrigerant Charge kg 0.55
Connection
Pipe
Length m 5
Gas Additional Charge g/m 20
Outer Diameter Liquid Pipe mm Φ6
Outer Diameter Gas Pipe mm Φ9.52
Max Distance Height m 10
Max Distance Length m 15
Note: The connection pipe applies metric diameter.
