Gree GWH09AAA-K3NNA2A

57
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH07AAA-K3NNA1A/I GWH09AAA-K3NNA2A/I GWH07AAA-K3NNA2A/I
Product Code CA115N13601 CA115N16501 CA115N14001
1 Front Panel 20000300001901T 20000300006001T 20000300006001T 1
2 Display Board 300001000037 300001000037 300001000037 1
3 Front Case 20000200000601 20000200000601 20000200000601 1
4 Axile Bush 10542036 10542036 10542036 1
5 Helicoid Tongue 200006000001 200006000001 200006000001 1
6 Left Axile Bush 10512037 10512037 10512037 1
7 Rear Case assy 000001000003 000001000003 000001000003 1
8 Cross Flow Fan 10352067 10352067 10352067 1
9 O-Gasket sub-assy of Bearing 7651205102 7651205102 7651205102 1
10 Ring of Bearing 26152022 26152022 26152022 1
11 Evaporator Support 200025000002 200025000002 200025000002 1
12 Evaporator Assy 011001000123 011001000123 011001000123 1
13 Fan Motor 15012115 15012115 15012115 1
14 Wall Mounting Frame Sub-assy 017211000005 017211000005 017211000005 1
15
Connecting pipe clamp 200017000001
200017000001 200017000001
1
16 Rubber Plug (Water Tray) 76712012 76712012 76712012 1
17 Stepping Motor 1521210811 1521210811 1521210811 1
18 Crank 73012005 73012005 73012005 1
19 Drainage Hose 0523001408 0523001408 0523001408 1
20 Electric Box Cover2 200082000005 200082000005 200082000005 1
21 Electric Box Assy 100002000648 100002000648 100002000648 1
22 Terminal Board 42010268 42010268 42010268 1
23 Jumper 4202021901 4202021901 4202021901 1
24 Main Board 30135000136 30135000136 30135000136 1
25 Power Cord 4002046439 4002046439 4002046439 1
26 Connecting Cable 40020540 40020540 40020540 0
27 Connecting Cable 40020536 40020536 40020536 0
28 Remote Controller 305001000009 305001000009 305001000009 1
