58
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH09AAB-K3NNA5A/I GWH07AAA-K3NNA5A/I GWH09AAA-K3NNA4A/I
Product Code CA488N00200 CA488N00100 CA479N02200
1 Front Panel 200003000117T01 200003000116T01 000003000148 1
2 Display Board 300001000041 300001000041 300001000041 1
3 Front Case 20000200000701 20000200000601 20000200000601 1
4 Axile Bush 10542036 10542036 10542036 1
5 Helicoid Tongue 200006000002 200006000001 200006000001 1
6 Left Axile Bush 10512037 10512037 10512037 1
7 Rear Case assy 000001000004 000001000003 000001000003 1
8 Cross Flow Fan 10352066 10352067 10352067 1
9 O-Gasket sub-assy of Bearing 7651205102 7651205102 7651205102 1
10 Ring of Bearing 26152022 26152022 26152022 1
11 Evaporator Support 200025000002 200025000002 200025000002 1
12 Evaporator Assy 011001000143 11001000123 011001000123 1
13 Fan Motor 150120874 15012115 15012115 1
14 Wall Mounting Frame Sub-assy 017211000005 017211000005 017211000005 1
15 Connecting pipe clamp 200017000001 200017000001 200017000001 1
16 Rubber Plug (Water Tray) 76712012 76712012 76712012 1
17 Stepping Motor 1521210811 1521210811 1521210811 1
18 Crank 73012005 73012005 73012005 1
19 Drainage Hose 0523001408 0523001408 0523001408 1
20 Electric Box Cover2 200082000005 200082000005 200082000005 1
21 Electric Box Assy 100002001760 100002001649 100002001649 1
22 Terminal Board 42010268 42010268 42010268 1
23 Jumper 4202021902 4202021901 4202021901 1
24 Main Board 30135000136 30135000136 30135000136 1
25 Power Cord 4002046439 4002046439 4002046439 1
26 Connecting Cable 40020540 40020540 40020540 0
27 Connecting Cable 40020536 40020536 40020536 0
28 Remote Controller 305001000054 305001000054 305001000009 1
To Next Page
