15
Technical Information
Service Manual
3. Outline Dimension Diagram
3.1 Indoor Unit

 W W1 W2 W3
 889 294 212 201.5 541.5 146
 1013 307 221 125.5 685 202.5
 1122 329 247 207 685 230




D
H
W
75
35
Φ55
W3W2
W1
Φ55
35
75
W1 W2 W3
140
190
38
Φ55
Φ55
38
79
154
43
W1 W2 W3
Φ70
Φ70
43
