Gree GWH09ACC-S6DBA1A User Manual

3
Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model GWH09ACC-S6DBA1A GWH12ACC-S6DBA1A
Product Code CB497009200 CB497010000/CB497010001
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50/60 50/60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 2700 3530
Heating Capacity W 3500 4200
Cooling Power Input W 580 840
Heating Power Input W 800 1000
Cooling Power Current A 3.66 5.6
Heating Power Current A 4.90 6.6
Rated Input W 2400 2500
Rated Current A 10.65 1138
Air Flow Volume(SH/H/MH/M/ML/L/SL) m
3
/h 680/550/500/460/430/400/320 680/620/560/490/450/420/390
Dehumidifying Volume L/h 0.8 0.8
EER W/W 4.66 4.20
COP W/W 4.38 4.20
SEER 7.8 7.60
HSPF / /
SCOP(Awerage/Warmer/Colder) 4.7/5.8/3.8 4.6/5.5/3.7
Application Area m
2
12-18 12-18
Indoor
Unit
Model of indoor unit GWH09ACC-S6DBA1A/I GWH12ACC-S6DBA1A/I
Indoor Unit Product Code CB497N09200 CB497N10000/CB497N10001
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Φ98X633.5 Φ98X633.5
Fan Motor Cooling Speed r/min 1300/1200/1120/1050/980/920/750/500 1350/1200/1120/1050/980/920/750/500
Fan Motor Heating Speed r/min 1300/1200/1140/1080/1020/960/850/- 1350/1200/1140/1080/1020/960/900/-
Output of Fan Motor W 20 20
Fan Motor RLA A 0.09 0.09
Fan Motor Capacitor μF / /
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Row-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 635X22.8X306.3 635X22.8X306.3
Swing Motor Model MP24EB MP24HF MP24EB MP24HF
Output of Swing Motor W 1.5 1.5 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level dB (A)
Cooling:41/39/36/34/32/31/25/21
Heating:41/39/37/35/33/32/30/-
Cooling:42/39/36/35/33/31/25/22
Heating:42/39/37/35/33/32/30/-
Sound Power Level dB (A)
Cooling:56/50/48/44/42/41/35/31
Heating:56/50/48/46/44/42/40/-
Cooling:58/49/46/45/43/41/35/32
Heating:54/49/47/45/43/42/40/-
Dimension (WXHXD) mm 899X294X212 899X294X212
Dimension of Carton Box (LXWXH) mm 935X349X273 935X349X273
Dimension of Package (LXWXH) mm 940X365X284 940X365X284
Net Weight kg 11 11
Gross Weight kg 13 13
