46
GWC09KF-K3DNA5A/O GWC12KF-K3DNA5A/O
Product Code CB146W0050 CB146W0070
1 Front Grill 22413017 22413017 1
2 Cabinet 01433044P 01433044P 1
3 Fan fixed nut 70313001 70313001 1
4 Axial Flow Fan Sub-Assy 1033300901 1033300901 1
5 Fan Motor 15013073 15013073 1
6 Motor Support 01703111 01703111 1
7 Chassis Sub-assy 0120390901P 0120390901P 1
8 Sound insulation Cotton 2 75013543 75013543 1
9 Sound insulation Cotton Assy 75013533 75013533 1
10 Left Side Plate 20053001 20053001 1
11 Damping Block 76713015 76713015 3
12 Valve Support 01713089 01713089 1
13 Cut-off Valve Assy 07133163 07133163 1
14 Capillary Sub-Assy 03103937 03103937 1
15 Compressor and fittings 00103761 00103761 1
16 Overload Protector 00181067 00181067 1
17 Overload Support 01743008 01743008 1
18 Terminal cap 22243001 22243001 1
19 Compressor fixed Bolt 01742005 01742005 3
20 Handle assy 26233046 26233046 1
21 Thermal baffle 26113005 26113005 1
22 Right Side Plate Sub-Assy 0130318001 0130318001 1
23 Condenser Assy 01113501 01113501 1
24 Temp sensor Support 24213042 24213042 1
25 Discharge Tube 03713424 03713055 1
26 Temperature Sensor clamp 02143022 02143022 1
27 Cut-off valve Sub-Assy 07133189 0710306001 1
28 Clapboard 01233088 01233088 1
29 Sound insulation Cotton 3 75013557 75013555 1
30 Sound insulation Cotton 4 75013556 75013556 1
31 Top Cover Sub-Assy 0125304001 0125304001 1
32 Electric Box Assy 0260325603 0260325601 1
33 Radiator 49013023 49013023 1
34 Electric Box 2 01413155 01413155 1
35 Electric Box 20113010 20113010 1
36 Filter Plate 30033069 30033069 1
37 Wiring 4011001930 4011001930 1
38 Temperature Sensor 39000304 39000304 1
39 Main Board 30138099 30138096 1
40 Magnetic Ring 49010109 49010109 1
41 Electric Box 1 01413154 01413154 1
42 Reactor 43130182 43130182 1
43 Terminal Board 42010312 42010312 1
44 Insulation Gasket 70413007 70413007 1
45 Cable clamp 26113010 26113010 1
Part Code
Description
No. Qty
Exploded Views and Parts list
The above data is subject to change without notice.
