Installation and Maintenance
Service Manual
Step Procedure
4. Remove grille
Remove connection screws between the front grille and
the front panel. Then remove the grille.
5. Remove front panel
Remove connection screws connecting the front panel
with the chassis and the motor support and then
remove the front panel.
6. Remove right side plate and left side plate
Remove connection screws connecting the right side
plate with the valve support and the electric box. Then
remove the right side plate.
Remove the screws fixing left side plate and then
remove the left side plate.
grille
front panel
right side plate
left side plate
