Technical Information
Service Manual
Model
GWH24QE-K6DNA5I
GWH24QE-K6DND2K
Product Code
CB425016401
CB461007801
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 7100
Heating Capacity W 7800
Cooling Power Input W 2030
Heating Power Input W 2000
Cooling Current Input A 9
Heating Current Input A 9.3
Rated Input W 3000
Rated Cooling Current A 13
Rated Heating Current A 13.5
Air Flow Volume m
3
/h 1250/1100/1000/950/900/850/800
Dehumidifying Volume L/h 2.40
EER W/W 3.50
COP W/W 3.90
SEER -- 7
SCOP (Warmer/Average/Colder) -- 5.4/4.2/3.4
Application Area m
2
27-42
Indoor Unit
Model
GWH24QE-K6DNA5I/I
GWH24QE-K6DND2K/I
Product Code
CB425N16400
CB461N07801
Fan Type Cross-ow
Fan Diameter Length(DXL) mm 108X830
Cooling Speed r/min 1250/1100/1000/950/900/850/800/600
Heating Speed r/min 1400/1250/1100/1050/1000/900/850
Fan Motor Power Output W 60
Fan Motor RLA A 0.24
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm 845X25.4X342.9
Swing Motor Model MP24HF/MP35CJ
Swing Motor Power Output W 1.5/2.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling:48/44/41/40/38/36/33
Heating:50/47/43/41/40/36/35
Sound Power Level dB (A)
Cooling:64/59/56/55/53/51/48
Heating:64/62/58/56/55/51/50
Dimension (WXHXD) mm 1135X328X247
Dimension of Carton Box (LXWXH) mm 1172X398X322
Dimension of Package (LXWXH) mm 1177X406X332
Net Weight kg 16.5
Gross Weight kg 19.5
