32
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GWH24AFE-K6DNA2I/O(LCLH)
Outdoor Unit Product Code CB363W04101
Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO.,LTD
Compressor Model QXFS-M180zX170
Compressor Oil FW68DA or equivalent
Compressor Type Twin Rotary
Compressor LRA. A 35.00
Compressor RLA A 3.50
Compressor Power Input W 1610
Compressor Overload Protector KSD115ºC HPC 115/95U1
Throttling Method Electron expansion valve
Set Temperature Range ºC 16~30
Cooling Operation Ambient Temperature Range ºC -15~50
Heating Operation Ambient Temperature Range ºC -25~30
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7
Condenser Rows-n Gap mm 2-1.4
Condenser Coil Length (LXDXW) mm 839X38.1X616
Fan Motor Speed rpm 800
Fan Motor Power Output W 60
Fan Motor RLA A 0.65
Fan Motor Capacitor μF /
Heater Power Input W /
Outdoor Unit Air Flow Volume m
3
/h 3600
Fan Type Axial-ow
Fan Diameter mm Φ520
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 59/-/-
Sound Power Level (H/M/L) dB (A) 70/-/-
Dimension(WXHXD) mm 958X660X402
Dimension of Carton Box (LXWXH) mm 1029X453X715
Dimension of Package(LXWXH) mm 1032X456X737
Net Weight kg 41.5
Gross Weight kg 46
Refrigerant R32
Refrigerant Charge kg 1.5
Connection
Pipe
Connection Pipe Length m 5
Connection Pipe Gas Additional Charge g/m 40
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 5/8
Max Distance Height m 10
Max Distance Length m 25
Note: The connection pipe applies metric diameter.
