6
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GWH07QA-K6DNC4A/O
Outdoor Unit Product Code CB444W13200
Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO.,LTD
Compressor Model FTz-AN075ACBF-A
Compressor Oil FW68DA
Compressor Type Rotary
Compressor LRA. A /
Compressor RLA A 3.00
Compressor Power Input W 633
Compressor Overload Protector /
Throttling Method Capillary
Set Temperature Range ºC 16~30
Cooling Operation Ambient Temperature Range ºC -15~43
Heating Operation Ambient Temperature Range ºC -15~24
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7
Condenser Rows-n Gap mm 1-1.4
Condenser Coil Length (LXDXW) mm 700X19.05X528
Fan Motor Speed rpm 900
Fan Motor Power Output W 30
Fan Motor RLA A 0.40
Fan Motor Capacitor μF /
Heater Power Input W /
Outdoor Unit Air Flow Volume m
3
/h 1950
Fan Type Axial-ow
Fan Diameter mm Φ400
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 51/-/-
Sound Power Level (H/M/L) dB (A) 62/-/-
Dimension(WXHXD) mm 732X550X330
Dimension of Carton Box (LXWXH) mm 789X390X600
Dimension of Package(LXWXH) mm 792X393X615
Net Weight kg 25
Gross Weight kg 27.5
Refrigerant R32
Refrigerant Charge kg 0.5
Connection
Pipe
Connection Pipe Length m 5
Connection Pipe Gas Additional Charge g/m 16
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 3/8
Max Distance Height m 10
Max Distance Length m 15
Note: The connection pipe applies metric diameter.
