7
Technical Information
Service Manual
Model
1.GWH09QA-K6DNB4A 2.GWH09QA-K6DNB2A
3.GWH09QA-K6DNB8A 4.GWH09QA-K6DNC4A
Product Code
1.CB434020401/CB434020402 2.CB432025401/CB432025402
3.CB438012600 4.CB444013800
Power
Supply
Rated Voltage V~
220-240
Rated Frequency Hz
50
Phases
1
Power Supply Mode
Outdoor
Cooling Capacity W
2500
Heating Capacity W
2800
Cooling Power Input W
720
Heating Power Input W
750
Cooling Current Input A
3.2
Heating Current Input A
3.2
Rated Input W
1500
Rated Cooling Current A
6
Rated Heating Current A
7.5
Air Flow Volume m
3
/h
500/420/390/300
Dehumidifying Volume L/h
0.80
EER W/W
3.47
COP W/W
3.73
SEER
-- 6.5
SCOP (Warmer/Average/Colder)
-- 5.1/4.1/-
Application Area m
2
12-18
Indoor Unit
Model
1.GWH09QA-K6DNB4A/I 2.GWH09QA-K6DNB2A/I
3.GWH09QA-K6DNB8A/I 4.GWH09QA-K6DNC4A/I
Product Code
1.CB434N20401/CB434N20402 2.CB432N25401/CB432N25402
3.CB438N12600 4.CB444N13800
Fan Type
Cross-ow
Fan Diameter Length(DXL) mm
Ф98X507
Cooling Speed r/min
1300/1200/1000/800
Heating Speed r/min
1300/1200/1000/800
Fan Motor Power Output W
10
Fan Motor RLA A
0.2
Fan Motor Capacitor μF
1
Evaporator Form
Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm
Φ5
Evaporator Row-n Gap mm
2-1.5
Evaporator Coil Length (LXDXW) mm
510X22.8X266.7
Swing Motor Model
MP24AA
Swing Motor Power Output W
1.5
Fuse Current A
3.15
Sound Pressure Level dB (A)
Cooling:39/36/32/25
Heating:39/36/33/26
Sound Power Level dB (A)
Cooling:55/48/44/37
Heating:49/48/45/38
Dimension (WXHXD) mm
713X270X195
Dimension of Carton Box (LXWXH) mm
760X334X259
Dimension of Package (LXWXH) mm
763X350X270
Net Weight kg
8
Gross Weight kg
9.5
