62
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH09QB-K3DNA1G/I
(Cold Plasma)
GWH09QB-K3DNA1G/I
Product Code CB419N05501 CB419N05500
1 Front Panel Assy 20022496 20022496 1
2 Display Board 30565231 30565231 1
3 Front Case Assy 20022495 20022495 1
4 Helicoid Tongue 26112508 26112508 1
5 Left Axile Bush 10512037 10512037 1
6 Rear Case assy 20162010 20162010 1
7 Drainage Hose 0523001408 0523001408 1
8 Ring of Bearing 26152022 26152022 1
9 Evaporator Support 24212180 24212180 1
10 Cold Plasma Generator 1114001602 / 1
11 Evaporator Assy 01002000044 01002000044 1
12 Wall Mounting Frame 01252043 01252043 1
13
Cross Flow Fan
10352059 10352059
1
14
Fan Motor 150120874 150120874 1
15 Connecting pipe clamp 2611216401 2611216401 1
16 Rubber Plug (Water Tray) 76712012 76712012 1
17 Stepping Motor 1521212901 1521212901 1
18 Crank 73012005 73012005 1
19 Electric Box Assy 10000201389 10000201390 1
20 Axile Bush 10542036 10542036 1
21 Terminal Board 42011233 42011233 1
22 Jumper 4202300101 4202300101 1
23 Main Board 30138000427 30130205 1
24 Electric Box Cover Sub-Assy 01402065 01402065 1
25 Shield Cover of Electric Box Cover 01592150 01592150 1
26 Electric Box Cover 20112207 20112207 1
27 Power Cord / / /
28 Connecting Cable 4002052317 4002052317 0
29 Remote Controller 30510474 30510474 1
30 Capacitor CBB61 33010747 33010747 1
To Next Page
