74
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
GWH12QC-K3DNA1G/O
Product Code CB419W05401 CB419W05400
1 Electric Box Assy 10000100120 10000100134 1
2 Electric Box Sub-Assy 10000500051 10000500055 1
3 Main Board 30138000456 30138000454 1
4 Reactor 43130184 43130184 1
5 Terminal Board 42010313 42010313 1
6 Wire Clamp 71010003 71010003 1
7 Front Grill 22413027 22413027 1
8 Front Panel Assy 0153304802 0153304802 1
9 Axial Flow Fan 10333004 10333004 1
10 Chassis Sub-assy 02803304P 02803151P 1
11 Fan Motor 1501308506 1501308506 1
12 Top Cover Sub-Assy 01253073 01253073 1
13 Motor Support 0170310401 0170310401 1
14
Condenser Assy 01100200142 01100200142 1
15 Rear Grill 01473009 01473009 1
16 Electric Expand Valve Fitting 4300876701 4300876701 1
17 Electronic Expansion Valve 07135228 07135228 1
18 Valve 07100003 07100003 1
19 Big Handle 262334332 262334332 1
20 Cut off Valve Assy 07133474 07133474 1
21 Valve Support 0171314201P 0171314201P 1
22 Right Side Plate Sub-Assy 0130317801 0130317801 1
23 4-Way Valve Assy 03015200075 03015200075 1
24 Clapboard Sub-Assy 0123338502 0123338502 1
25 Magnet Coil 4300040050 4300040050 1
26 Compressor and Fittings 0010322402 0010322402 1
27 Electrical Heater 7661281401 / 1
28 Drainage Connecter 06123401 06123401 1
29 Electrical Heater (Chassis) 7651000414 / 1
To Next Page
