Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Outdoor Unit Model
GWH09TB-S3DNA1D/O GWH09TB-S3DNA1D/O
Outdoor Unit Product Code
CB148W08400 CB148W08401
Compressor Manufacturer
ZHUHAI GREE DAIKIN DEVICE CO.,
LTD
ZHUHAI GREE DAIKIN DEVICE CO.,
LTD
Compressor Model
1GDY23AXD 1GDY23AXD
Compressor Oil
FVC50K FVC50K
Compressor Type
Rotary Rotary
Compressor LRA.
A 16.5 16.5
Compressor RLA
A 4 4
Compressor Power Input
W 845 845
Compressor Overload Protector
HPC 115/95 HPC 115/95
Throttling Method
Electron expansion valve Electron expansion valve
Set Temperature Range °C
16~30 16~30
Cooling Operation Ambient
Temperature Range
°C
-15~48 -15~48
Heating Operation Ambient
Temperature Range
°C
-20~24 -7~24
Condenser Form
Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter
mm Φ7.94 Φ7.94
Condenser Rows-n Gap
mm 2.5-1.5 2.5-1.5
Condenser Coil Length (LXDXW)
mm 733X57X550 733X57X550
Fan Motor Speed
rpm 900/600 900/600
Fan Motor Power Output
W 30 30
Fan Motor RLA
A 0.15 0.15
Fan Motor Capacitor
μF / /
Outdoor Unit Air Flow Volume
m
3
/h 2400 2400
Fan Type
Axial-ow Axial-ow
Fan Diameter
mm Φ438 Φ438
Defrosting Method
Automatic Defrosting Automatic Defrosting
Climate Type
T1 T1
Isolation
I I
Moisture Protection
IP24 IP24
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H/M/L)
dB (A) 54/-/- 54/-/-
Sound Power Level (H/M/L)
dB (A) 63/-/- 63/-/-
Dimension (WXHXD)
mm 899X596X378 899X596X378
Dimension of Carton Box (LXWXH)
mm 945X417X630 945X417X630
Dimension of Package (LXWXH)
mm 948X420X645 948X420X645
Net Weight
kg 41 41
Gross Weight
kg 44 44
Refrigerant
R410A R410A
Refrigerant Charge
kg 1.2 1.2
Connection
Pipe
Connection Pipe Length
m 5 5
Connection Pipe Gas Additional
Charge
g/m 20 20
Outer Diameter Liquid Pipe
mm Φ6 Φ6
Outer Diameter Gas Pipe
mm Φ9.52 Φ9.52
Max Distance Height
m 10 10
Max Distance Length
m 15 15
Note: The connection pipe applies metric diameter.
