67
Service Manual
Installation and Maintenance
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWH09TB-S3DNA1D/I GWH09TB-S3DNA2D/I
Product Code CB148N08400 CB411N02902
1 Front Panel 20012850T 20022266 1
2 Display Board 30565140 30565145 1
3 Filter Sub-Assy 1112211602 1112211602 2
4 Front Case Sub-assy 2001288901 00000200088 1
5 Guide Louver 10512147 1051214702 1
6 Guide Louver (small) 10512127 10512127 1
7 Crank 10582070 10582070 2
8 Air Louver (left) 10512232 10512232 1
9 Helicoid Tongue sub-assy 2611224401 2611224401 1
10 Left Axile Bush 10512037 10512037 2
11 Step Motor 15212123 15212123 1
12 Propeller Axile Bush 1054202101 1054202101 1
13 Evaporator Support 24212114 24212114 1
14 Cold Plasma Generator 1114001601 1114001601 1
15 Evaporator Assy 0100294511 0100294511 1
16 Cross Flow Fan 10352033 10352033 1
17 Drainage Hose 05230014 05230014 1
18 Fan Motor 15012510 15012510 1
19 Wall Mounting Frame 01252484 01252484 1
20 Motor Press Plate 26112209 26112209 1
21 Rubber Plug (Water Tray) 76712012 76712012 1
22 Pipe Clamp 2611216402 2611216402 1
23 Rear Case assy 2220216104 2220216104 1
24 Axile Bush 10542036 10542036 3
25 Step Motor 15212125 15212125 1
26 Step Motor 15212126 15212126 1
27 Electric Box 20112181 20112181 1
28 Electric Box Cover 2012240901 2012240901 1
29 Jumper 4202300102 4202300102 1
30 Main Board 30138000636 30138000636 1
31 Electric Box Assy 10000201684 10000202927 1
32 Terminal Board 42011233 42011233 1
33 Electric Box Cover2 20122075 2012207507 1
34 Screw Cover 24252016 242520179 1
35 Pipe Connection Nut accessories 06320020 06320020 1
36 Temperature Sensor 390000598 390000598 1
37 Connecting Cable 4002052317 4002052317 0
38 Temperature Sensor 390000451 390000451 1
39 Remote Controller 30510137 30510137 1
To Next Page
