7
Technical Information
Service Manual
Model
1.GWH12QD-S6DBC2A 2.GWH12QD-S6DBD2A
3.GWH12QD-S6DBE4A 4.GWH12QD-S6DBE6A
5.GWH12QD-S6DBD6A
Product Code
1.CB439014808 2.CB461006208
3.CB470005108 4.CB465003408
5.CB460006908
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50/60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 3530
Heating Capacity W 4200
Cooling Power Input W 840
Heating Power Input W 950
Cooling Power Current A 5.10
Heating Power Current A 5.70
Rated Input W 2600
Rated Current A 8.2
Air Flow Volume(SH/H/MH/M/ML/L/SL) m
3
/h 800/730/680/630/580/450/350
Dehumidifying Volume L/h 1.40
EER W/W 4.20
COP W/W 4.42
SEER W/W 8.50
HSPF W/W /
SCOP(Awerage/Warmer/Colder) 5.1/5.7/4
Application Area m
2
16-24
Indoor Unit
Model of indoor unit
1.GWH12QD-S6DBC2A/I 2.GWH12QD-S6DBD2A/I
3.GWH12QD-S6DBE4A/I 4.GWH12QD-S6DBE6A/I
5.GWH12QD-S6DBD6A/I
Indoor Unit Product Code
1.CB439N14800 2.CB461N06200
3.CB470N05100 4.CB465N03400
5.CB460N06900
Fan Type Cross-ow
Diameter Length(DXL) mm Φ106X706
Fan Motor Cooling Speed r/min 1200/1100/1030/960/820/650/600/500
Fan Motor Heating Speed r/min 1300/1200/1120/1040/880/700/650/-
Output of Fan Motor W 60
Fan Motor RLA A 0.24
Fan Motor Capacitor μF /
Input of Heater W /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Row-n Gap mm 2-1.4
Coil Length (LXDXW) mm 715X25.4X304.8
Swing Motor Model MP35CJ/MP24HF
Output of Swing Motor W 2.5/1.5
Fuse A 3.15
Sound Pressure Level (SH/H/MH/M/ML/L/
SL)
dB (A) 44/43/38/36/31/24/22
Sound Power Level (SH/H/MH/M/ML/L/SL) dB (A) 58/53/48/46/41/34/32
Dimension (WXHXD) mm 970X300X224
Dimension of Carton Box (LXWXH) mm 1038X380×X305
Dimension of Package (LXWXH) mm 1041X383X320
Net Weight kg 13.5
Gross Weight kg 16.5
