Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model GWH09QC-S6DBC8A GWH12QC-S6DBC8A
Product Code CB456007000 CB456006900
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50/60 50/60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 2700 3530
Heating Capacity W 3500 4200
Cooling Power Input W 580 840
Heating Power Input W 800 1000
Cooling Power Current A 3.66 5.6
Heating Power Current A 4.90 6.6
Rated Input W 2400 2500
Rated Current A 6.76 9
Air Flow Volume(SH/H/MH/M/ML/L/SL) m
3
/h 680/550/500/460/430/400/320 680/620/560/490/450/420/390
Dehumidifying Volume L/h 0.8 1
EER W/W 4.66 4.20
COP W/W 4.38 4.20
SEER W/W 7.8 7.60
HSPF / /
SCOP(Awerage/Warmer/Colder) 4.7/5.8/3.8 4.6/5.5/3.7
Application Area m
2
12-18 12-18
Indoor
Unit
Model of indoor unit GWH09QC-S6DBC8A/I GWH12QC-S6DBC8A/I
Indoor Unit Product Code CB456N07000 CB456N06900
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Φ98X633.5 Φ98X633.5
Fan Motor Cooling Speed (SH/H/MH/M/ML/L/SL/
SM)
r/min 1300/1200/1120/1050/980/920/750/500 1350/1200/1120/1050/980/920/750/500
Fan Motor Heating Speed(SH/H/MH/M/ML/L/SL/
SM)
r/min 1300/1200/1140/1080/1020/960/900/- 1350/1200/1140/1080/1020/960/900/-
Output of Fan Motor W 20 20
Fan Motor RLA A 0.09 0.09
Fan Motor Capacitor μF / /
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Row-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 635X22.8X306.3 635X22.8X306.3
Swing Motor Model MP24BA/MP24EB MP24EB/MP24HF
Output of Swing Motor W 1.5/1.5 1.5/1.5
Fuse A 3.15 3.15
Sound Pressure Level (SH/H/MH/M/ML/L/SL/SM) dB (A) 41/39/36/34/32/31/25/- 42/39/36/35/33/31/25/22
Sound Power Level (SH/H/MH/M/ML/L/SL/SM) dB (A) 56/49/46/44/42/41/35/- 58/49/46/45/43/41/35/32
Dimension (WXHXD) mm 845X289X209 845X289X209
Dimension of Carton Box (LXWXH) mm 918X278X364 918X278X364
Dimension of Package (LXWXH) mm 921X281X379 921X281X379
Net Weight kg 10.5 11
Gross Weight kg 12.5 13
