Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GWH07AGA-K3NNA1B/O GWH09AGB-K3NNA1B/O
Outdoor Unit Product Code CA385W00300 CA385W00200
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO.,LTD
ZHUHAI LANDA
COMPRESSOR CO.,LTD
Compressor Model QXA-A081T130A QXA-B102C130
Compressor Oil RB68EP/FVC68D/FV50S RB68EP/FV50S
Compressor Type Rotary Rotary
Compressor LRA. A 15 17
Compressor RLA A 3.25 4
Compressor Power Input W / 865
Compressor Overload Protector UP3-MC0 UP3- 00
Throttling Method Capillary Capillary
Set Temperature Range ºC 16~30 16~30
Cooling Operation Ambient Temperature Range ºC 18~43 18~43
Heating Operation Ambient Temperature Range ºC -15~24 -15~24
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7.94 Φ7.94
Condenser Rows-n Gap mm 1-1.4 1-1.4
Condenser Coil Length (LXDXW) mm 658.3×19.05×396 655×19.05×396
Fan Motor Speed rpm 950 950
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.25 0.25
Fan Motor Capacitor μF 1.5 1.5
Outdoor Unit Air Flow Volume m
3
/h 1200 1200
Fan Type Axial-ow Axial-ow
Fan Diameter mm 320 320
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H/M/L) dB (A) 48 48
Sound Power Level (H/M/L) dB (A) 58 58
Dimension(WXHXD) mm 720X428X310 720X428X310
Dimension of Carton Box (LXWXH) mm 765X350X475 765X350X475
Dimension of Package(LXWXH) mm 768X353X490 768X353X490
Net Weight kg 23.4 25.5
Gross Weight kg 25.4 27.5
Refrigerant R410A R410A
Refrigerant Charge kg 0.52 0.63
Connection
Pipe
Connection Pipe Length m 5 5
Connection Pipe Gas Additional Charge g/m 20 20
Outer Diameter Liquid Pipe inch 1/4" 1/4"
Outer Diameter Gas Pipe inch 3/8" 3/8"
Max Distance Height m 10 10
Max Distance Length m 15 15
Note: The connection pipe applies metric diameter.
