5
Technical Information
Service Manual
Model GWH09AGA-K3NNA1A GWH12AGB-K3NNA1A
Product Code
CA385001000
CA385001001
CA385001100
CA385001101
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Indoor Indoor
Cooling Capacity W 2550 3250
Heating Capacity W 2650 3400
Cooling Power Input W 794 985
Heating Power Input W 734 941
Cooling Current Input A 3.7 4.62
Heating Current Input A 3.4 4.41
Rated Input W 1120 1250
Rated Cooling Current A 6.2 5.6
Rated Heating Current A 5.2 5.38
Air Flow Volume(SS/H/MH/M/ML/L/SL/SM) m
3
/h 520/470/450/420/310/290/250 590/520/482/440/402/348/333
Dehumidifying Volume L/h 0.8 1.4
EER W/W 3.21 3.3
COP W/W 3.61 3.61
SEER W/W / /
HSPF W/W / /
Application Area m
2
12-18 16-24
Indoor Unit
Model GWH09AGA-K3NNA1A/I GWH12AGB-K3NNA1A/I
Product Code
CA385N01000
CA385N01001
CA385N01100
CA385N01101
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Φ93×505 Φ93×580
Cooling Speed r/min
1300/1200/1150/1100
/900/850/750
1350/1200/1150/1100
/1050/950/900
Heating Speed r/min
1200/1100/1050/1000
/950/900/800
1350/1200/1150/1100
/1000/900/850
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.2 0.22
Fan Motor Capacitor μF 1 1
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7.94 Φ7.94
Evaporator Row-n Gap mm 1-1.2 1-1.2
Evaporator Coil Length (LXDXW) mm 508×19.05×254 583×19.05×264
Swing Motor Model MP24BA/MP24AK MP24BA/MP24AK
Swing Motor Power Output W 1.5/1.5 1.5/1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A)
Cooling:40/37/36/34/29/27/24
Heating:37/34/33/32/30/27/24
Cooling:41/37/36/34/33/30/28
Heating:41/37/36/34/32/28/27
Sound Power Level dB (A)
Cooling:50/47/46/44/39/37/34
Heating:47/44/43/42/40/37/34
Cooling:51/47/46/44/43/40/38
Heating:51/47/46/44/42/38/37
Dimension (WXHXD) mm 704X260X185 779X260X185
Dimension of Carton Box (LXWXH) mm 748X316X247 823X316X247
Dimension of Package (LXWXH) mm 753X332X258 828X332X258
Net Weight kg 7.5 8.2
Gross Weight kg 8.7 9.7
