74
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
QtyGWH24MD-K3DNB3G/I GWH24MD-K3DNC9G/I
Product Code CB163N06900 CB145N05800
1 Front Panel Assy 20012483 20012702 1
2 Filter Sub-Assy 11122091 11122091 2
3 Screw Cover 24252016 24252016 3
4 Front Case Assy 2001232905 20012329 1
5 Air Louver 1 10512159 10512159 3
6 Helicoid Tongue 26112187 26112187 1
7 Left Axile Bush 10512037 10512037 1
8 Rear Case assy 00000100013 00000100013 1
9 Rubber Plug (Water Tray) 76712012 76712012 1
10 Ring of Bearing 26152025 26152025 1
11 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
12 Cross Flow Fan 10352045 10352045 1
13 Evaporator Support 24212139 24212139 1
14 Evaporator Assy 01100100032 01100100032 1
15 Wall Mounting Frame 01252032 01252032 1
16 Motor Press Plate 26112330 26112330 1
17 Fan Motor 15012098 15012098 1
18 Connecting pipe clamp 26112188 26112188 1
19 Drainage Hose 0523001405 0523001405 1
20 Stepping Motor 1521300101 1521300101 1
21 Crank 10582070 10582070 1
22 Display Board 30565037 30565107 1
23 Guide Louver 10512118 10512118 1
24 Axile Bush 10542036 10542036 2
25 Electric Box 2011210801 2011210801 1
26 Terminal Board 42011233 42011233 1
27 Shield Cover of Electric Box 01592092 01592092 1
28 Main Board 30138000402 30138000402 1
29 Electric Box Cover1 20122154 20122154 1
30 Electric Box Cover2 20112081 20112081 1
31 Jumper 4202300110 4202300110 1
32 Capacitor CBB61 3301074703 3301074703 1
33 Electric Box Assy 10000202257 10000202430 1
34 Connecting Cable 4002052317 4002052317 0
35 Temperature Sensor 390000451 390000451 1
36 Temperature Sensor 390000597 390000597 1
37 Remote Controller 305100491 305100491 1
38 Power Cord / / /
39 Cold Plasma Generator / / /
