36
Technical Information
Service Manual
18K
GWH12AGC-K6DNA1A/I
GWH24AGD-K6DNA1C/I
No Name
1
Terminal of communication
2
3
Jumper cap
Live wire terminal
PG Motor terminal
4
Neutral wire terminal
5
6
Fuse
7Interface of health function
Up&down swing interface 28
Up&down swing interface 1
9
10
12
Left &Right swing interface
13
Terminal of temperature sensor
14
Interface of gate-control (only for the
model with thisfunction)
15
Wired controller terminal (only for
the model with this function)
16
Terminal of live wire used for
supplying power for outdoor unit
11 Interface of PG feedback
display interface
● Top view
● Bottom view
1
16
2
3
456789 10 11
12
13
14
15
