5
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit GWH09AGA-K6DNA1A/O GWH12AGB-K6DNA1A/O
Product Code of Outdoor Unit CB385W01000 CB385W01700
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO.,LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model FTz-AN075ACBF-A FTz-AN088ACBF-A
Compressor Oil FW68DA FW68DA
Compressor Type Rotary Rotary
L.R.A. A 20.00 /
Compressor RLA A 3.00 3.60
Compressor Power Input W 633 758
Overload Protector / /
Throttling Method Capillary Capillary
Operation Temp
o
C 16~30 16~30
Ambient Temp (Cooling)
o
C -15~43 -15~43
Ambient Temp (Heating)
o
C -15~24 -15~24
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 1-1.4 1-1.4
Coil Length (LXDXW) mm 700X19.05X528 700X19.05X528
Fan Motor Speed rpm 900 900
Output of Fan Motor W 30 30
Fan Motor RLA A 0.40 0.40
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit m
3
/h 2200 2200
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ400 Φ400
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H/M/L) dB (A) 51/-/- 51/-/-
Sound Power Level (H/M/L) dB (A) 62/-/- 64/-/-
Dimension (WXHXD) mm 732X550X330 732X550X330
Dimension of Carton Box (LXWXH) mm 789X390X600 789X390X600
Dimension of Package (LXWXH) mm 792X393X615 792X393X615
Net Weight kg 25 25
Gross Weight kg 27.5 27.5
Refrigerant R32 R32
Refrigerant Charge kg 0.5 0.55
Connection
Pipe
Length m 5 5
Gas Additional Charge g/m 16 16
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 3/8 3/8
Max Distance Height m 10 10
Max Distance Length m 15 15
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
